FAQ's - 20A MPPT In-Line Solar ControllerUpdated 2 hours ago
How can I purchase the 20A MPPT In-Line Solar Charge Controller?
You can purchase the 20A MPPT In-Line Solar Charge Controller online here, call our sales team on (07) 3123 4715, or locate a store near you.
Where can I find the user manual for the 20A MPPT In-Line Solar Charge Controller?
You can find the user manual on our Support Portal.
What is the IP Rating of the 20A MPPT In-Line Solar Charge Controller?
The 20A MPPT In-Line Solar Charge Controller has an IP45 Rating. This protects the unit from dust and debris, and water spray.
What size solar panel should I use to get the most charge from the 20A MPPT Charger?
To achieve the maximum 20A charge current, your solar setup should meet the following input power requirements:
System Voltage | 12V | 24V |
Solar Bank | 300W | 600W |
What is the maximum solar input voltage for the 20A MPPT In-Line Solar Charge Controller?
The maximum solar input voltage (VOC) for the 20A MPPT In-Line Solar Charge Controller is as follows:
| System Voltage | 12V | 24V |
| Maximum Solar Input (VOC) | 30V | 60V |
What battery types can be used with the 20A MPPT In-Line Solar Charge Controller?
The 20A MPPT In-Line Solar Charge Controller supports AGM, GEL, and LiFePO4 battery types.
Does the 20A MPPT In-Line Solar Charge Controller have Bluetooth?
Yes. The 20A MPPT In-Line Solar Charge Controller has built-in Bluetooth. Simply download the KA Solar app from Google Play or the Apple App Store.
When do I need to configure the 20A MPPT In-Line Solar Charge controller?
Configuration of the 20A MPPT In-Line Solar Charge Controller is only required if you are using a Lithium (LiFePO4) battery.
What happens if I don’t select the correct battery type on the 20A MPPT In-Line Solar Charge Controller?
Choosing the correct battery type on the 20A MPPT In-Line Solar Charge Controller ensures optimal charging performance and maximum battery efficiency. For the best results, always select the mode that matches your battery system.
Why isn’t my battery charging from solar when using the 20A MPPT In-Line Solar Charge Controller?
The solar panel voltage must be at least 3V higher than the battery voltage for proper charging. For a 12V battery setup, the solar panel must supply more than 15V. Also ensure the solar panel is not shaded or only partially exposed to sunlight, as this will reduce performance and prevent charging.
What are the dimensions and weight of the 20A MPPT In-Line Solar Charge Controller?
The dimensions of the 20A MPPT In-Line Solar Charge Controller are 150mm (L) x 80mm (W) x 35mm (H)
Weight: 0.35kg
SKU: KA24MPPTIL20A
