FAQ's - 170W Flexible Solar PanelUpdated 5 days ago
How can I purchase the 170W Flexible Solar Panel?
You can purchase the 170W Flexible Solar Panel online here, call our sales team on (07) 3123 4715, or locate a store near you.
Where can I find the user manual for the 170W Flexible Solar Panel?
You can find the user manual on our Support Portal.
What is the maximum bend angle of the 170W Flexible Solar Panel?
The 170W Flexible Solar Panel can be bent up to 270°, allowing it to conform to curved surfaces.
Can I permanently mount the 170W Flexible Solar Panel?
Yes. The 170W Flexible Solar Panel can be mounted using adhesive, screws, or alternative mounting solutions designed for flexible panels.
Can I connect the 170W Flexible Solar Panel directly to a 12V battery?
Not directly, you must always use a solar regulator, such as the 20A Inline MPPT, between the 170W Flexible Solar Panel and a 12V battery to ensure safe and proper charging.
How do I connect the 170W Flexible Solar Panel to a KickAss Battery Box with DCDC charger?
The 170W Flexible Solar Panel is fitted with MC4 connectors. To connect it to a KickAss Battery Box with a DCDC charger or to a KickAss Control Hub with DCDC charger, you will need a KickAss Solar Panel PV to Anderson Extension Cable.
Why is my 170W Flexible Solar Panel providing low output?
Reduced output can be caused by shading or dirt on the panel. Please ensure the 170W Flexible Solar Panel is clean and fully exposed to direct sunlight, as even partial shading can significantly reduce its performance.
What is the open-circuit voltage (Voc) of the 170W Flexible Solar Panel?
The open-circuit voltage of the 170W Flexible Solar Panel is 24.8V.
What type of cells are used in the 170W Flexible Solar Panel?
The 170W Flexible Solar Panel uses N-Type TOPCon monocrystalline silicon cells.
What is the IP Rating of the 170W Flexible Solar Panel?
The 170W Flexible Solar Panel has an IP67 rating, making it durable and suitable for outdoor environments.
What are the dimensions and weight of the 170W Flexible Solar Panel?
The 170W Flexible Solar Panel dimensions are 1210mm (L) x 790mm (W) x 3mm (H)
Weight: 3.2 kg
SKU: KAFLXSP170
