FAQ's - 125Ah Lithium Power StationUpdated 36 minutes ago
How can I purchase the 125Ah Lithium Power Station?
You can purchase the 125Ah Lithium Power Station online here, call our sales team on (07) 3123 4715, or locate a store near you.
Where can I find the user manual for the 125Ah Lithium Power Station?
You can find the user manual on our Support Portal.
How many inputs and outputs does the 125Ah Lithium Power Station have?
3 x Dual Sets of Anderson Input/Outputs (6 total) | 50A shared circuit breaker |
1 x Three-Pin Anderson Socket (Input/Output) | 120A maximum |
2 x Cigarette Sockets (Output) | 10A max (shared) |
2 x USB-C (Output) | 45W |
2 x USB-A 3.0 (Output) | 18W |
What DCDC charger is connected to the 125Ah Lithium Power Station?
The 125Ah Lithium Power Station includes an inbuilt 25A DCDC charger with Bluetooth.
What size inverter can I use with the 125Ah Lithium Power Station?
The 125Ah Lithium Power Station can operate inverters up to 1200W. It works great with the KickAss 1000W Inverter, providing reliable power for a wide range of appliances and equipment.
How do you secure the 125Ah Lithium Power Station in a vehicle?
The 125Ah Lithium Power Station is compatible with our Battery Box Tray, which is available as an optional accessory, perfect for added stability and protection.
Can I connect an unregulated solar panel directly to the 125Ah Lithium Power Station?
Yes, you can, but it must be connected to the dedicated solar input Anderson port located on the back of the lid. This port is internally wired to the unit’s built-in DCDC/MPPT solar regulator.
Important: Do not connect unregulated panels to other ports, as they bypass the built-in regulator and may damage the system.
What remote displays can I use with the 125Ah Lithium Power Station?
The 125Ah Lithium Power Station has an in-built display screen to monitor battery state of charge, voltage, current, and temperature. Alternatively, you can connect to the Bluetooth app.
Can I remove the battery from the 125Ah Lithium Power Station?
No. The battery on the 125Ah Lithium Power Station is integrated into the lower portion of the unit and cannot be removed.
Does the 125Ah Lithium Power Station have a mobile app?
You can download the KickAss Mobile App from the Apple App Store or Google Play Store to monitor and manage your Power Stations battery.
You can also monitor your DCDC performance via the KA Charge App.
Can the Lithium 125Ah Lithium Power Station work with other battery brands?
The 125Ah Lithium Power Station includes a built-in battery as the base. There is no option to use another brand of battery.
What protection features does the 125Ah Lithium Power Station have?
The 125Ah Lithium Power Station is equipped with a KickAss Battery Management System (BMS) and multi-voltage protection features, including over-voltage, under-voltage, overcharge, and over-discharge protection, ensuring safe and reliable operation.
How do I charge the 125Ah Lithium Power Station?
The 125Ah Lithium Power Station can be charged using the integrated DCDC charger via solar or alternator, or an external ACDC charger. Always charge the battery every three months to maintain a healthy battery life.
What is the recommended ACDC charger for the 125Ah Lithium Power Station?
For the fastest and most efficient charging of the 125Ah Lithium Power Station, the 32A ACDC Smart Charger or 50A ACDC Smart Charger is recommended.
Does the master switch of the 125Ah Power Station disconnect everything?
The master switch of the 125Ah Power Station disconnects everything except for the 120A Anderson-style plug and the LCD screen.
How do I switch the display from Page 1 to Page 2 on the 125Ah Lithium Power Station?
To switch the display, simply press the A button on the 125Ah Lithium Power Station.
Is the screen time duration of the 125Ah Lithium Power Station adjustable?
Yes. The screen time in the 125Ah Lithium Power Station can be set to 30 seconds, 1 minute, 2 minutes, 5 minutes, or 1 hour.
What are the dimensions and weight of the 125Ah Lithium Power Station?
The dimensions of the 125Ah Lithium Power Station are 430mm (L) x 260mm (W) x 398mm (H)
Weight: 18.15 kg
SKU: KAJBBOX125AH25A
